CHAINSAWS
TOP HANDLE CHAINSAW
T525
T435
T540 XP II
TECHNICAL SPECIFICATIONS
Cylinder displacement, cc
27.0
35.2
37.7
Power output, hp
1.5
2
2.4
Sound pressure level at operators ear,
dB(A)*
98
103
104
Sound power level guaranteed
(LWA) dB(A)**
111
114
116
Equivalent vibration level (ahv, eq)
front / rear handle, m/s²***
4.9 / 5 .2 3.6 / 3.9 3.5 / 4.2
Chain pitch, inches
1/4
3/8
3/8
Recommended bar length,
min–max, inches
12
12 – 16 14 – 16
Weight (excl. cutting equipment), lbs 6.0
7.5
8.6
FEATURES
Adjustable oil pump
•
•
•
Air Injection™
•
—
•
AutoTune™
—
—
•
Purge bulb
•
•
•
Horizontal rope eye let
•
—
•
Inertia chain brake
•
•
•
Low Vib®
•
•
•
Magnesium crankcase
—
—
•
Quick-release air filter cover
•
•
•
Quick-release air filter
•
•
•
Visible fuel level
•
—
•
X-Torq® engine
•
•
•
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for different sound pressure levels under various working
conditions. Typical statistical dispersion for equivalent sound pressure level is a standard deviation of 1 dB (A). **Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC.
The guaranteed sound power level includes variation in production as well as variation from the test code with 1–3 dB(A). ***Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for
vibration levels under various working conditions. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
POLE SAWS
525P4S 525P5S 525PT5S
TECHNICAL SPECIFICATIONS
only
Cylinder displacement, cc
25.4
25.4
25.4
Power output, hp
1.34
1.34
1.34
Sound pressure level at operators ear,
dB(A)*
91
90
89
Sound power level guaranteed
(LWA) dB(A)
107
107
107
Equivalent vibration level (ahv, eq)
front / rear handle, /s²**
2.9 / 3.2 2.9 / 3.2 6.3 / 5.3
Chain pitch, inches
3/8 mini
3/8 mini
1/4
Recommended bar length,
min–max, inches
12
12
12
Max. length with cutting equipment, ft
13
16
16
Weight (excl. cutting equipment), lbs 11.7
14.1
15.4
FEATURES
Auto return stop switch
•
•
•
Chain lubrication
•
•
•
Chain tensioner
•
•
•
Detachable shaft
—
•
—
Purge bulb
•
•
•
Inertia balancing wheel
•
•
—
Rear impact guard
•
•
•
Stand alone starter
•
•
•
Telescopic tube
—
—
•
ELECTRIC CHAINSAW
414EL
TECHNICAL SPECIFICATIONS
Voltage, V
120
Power rating, W
14.5
Vibrations front / rear handle (a hv, eq), m/s² *
5.2 / 3.9
Weight (excl. cutting equipment and cable), lbs
9.7
Chain pitch, inches
3/8
Recommended bar length, min–max, inches
16
FEATURES
Electronic SoftStart™
•
Inertia chain brake
•
Overspeed protection
•
Window for oil level
•
