56 / 253
56
CHAINSAWS
TECHNICAL SPECIFICATIONS
562 XP® / XP G® 565
572 XP®
572 XP G®
390 XP® 395 XP® 3120 XP®
TECHNICAL SPECIFICATIONS
Cylinder displacement, cc
59.8
70.6
70.6
70.6
88.0
94.0
118.8
Power output, hp
4.8
5.0
5.8
5.8
6.5
7.1
8.4
Sound pressure level at operators ear, dB(A)* 106
105
107
107
107
102
102
Sound power level guaranteed (LWA) dB(A)** 118
119
120
120
119
115
116
Equivalent vibration level (ahv, eq) front /
rear handle, m/s²***
3.2 / 5.0
5.2 / 5.3
5.0 / 4.1
5.0 / 4.1
3.5 / 6.2
6.5 / 10.2
6.7 / 7.8
Chain pitch, inches
3/8
3/8
3/8
3/8
3/8
3/8 / .404 .404
Recommended bar length, min–max, inches
18 – 28
20 – 28
20 – 32
20 – 32
20 – 36
20 – 36
24 – 42
Weight (excl. cutting equipment), lbs
13.4
14.3
14.5
15
16.1
17.4
22.9
FEATURES
Adjustable oil pump
•
•
•
•
•
•
•
Air Injection™
•
•
•
•
•
•
—
AutoTune™
•
•
•
•
—
—
—
Combined choke /stop control
•
•
•
•
—
—
—
Purge bulb
•
•
•
•
—
—
—
Heated carburetor
— / •
—
—
•
—
—
—
Heated handles
— / •
—
—
•
—
—
—
Inertia chain brake
•
•
•
•
•
•
•
LowVib®
•
•
•
•
•
•
•
Magnesium crankcase
•
•
•
•
•
•
•
Quick-release air filter cover
•
•
•
•
•
•
•
Quick-release air filter
•
•
•
•
•
•
•
Retained bar nuts
•
•
•
•
—
—
—
RevBoost™
•
—
—
—
—
—
—
Side-mounted chain tensioner
•
•
•
•
•
—
—
SmartStart®
•
•
•
•
•
•
•
Snap-lock cylinder cover
•
•
•
•
—
—
—
Tool-less chain tensioning
—
—
—
—
—
—
—
TrioBrake™
—
—
—
—
—
—
—
Visible fuel level
•
•
•
•
—
—
—
X-Torq® engine
•
•
•
•
—
—
—
ALWAYS USE GENUINE HUSQVARNA LUBRICANTS
AND SPARE PARTS FOR YOUR CHAINSAW
These high quality spare parts and lubricants are developed to facilitate the care and maintenance of your Husqvarna equipment and enable
trouble-free operation and storage. Husqvarna recommends regular service done by qualified technicians using only Genuine Husqvarna original or
recommended spare parts. This will support the product’s performance and lifetime. See your owner’s manual or consult your Authorized Husqvarna
dealer if any uncertainty occurs.
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for different sound pressure levels under various working
conditions. Typical statistical dispersion for equivalent sound pressure level is a standard deviation of 1 dB (A). **Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC.
The guaranteed sound power level includes variation in production as well as variation from the test code with 1–3 dB(A). ***Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for
vibration levels under various working conditions. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
NOMINAL POWER
–
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard
J 1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
For battery chainsaw and pole saw technical specifications, please see page 26.
