CHAINSAWS
TECHNICAL SPECIFICATIONS
120 II
130
135 II
435e II
440e II
445e II
TECHNICAL SPECIFICATIONS
Cylinder displacement, cc
38.2
38
38
40.9
40.9
50.2
Power output, hp
2.0
2.0
2.2
2.2
2.4
2.8
Sound pressure level at operators ear, dB(A)*
101
102
102
102
102
103
Sound power level guaranteed (LWA) dB(A)**
113
114
116
114
114
114
Equivalent vibration level (ahv, eq) front / rear handle, m/s²*** 2.1 / 2.7
3.7 / 5.5
3.7 / 5.5
3.8 / 4.2
3.8 / 4.2
1.9 / 4.9
Chain pitch, inches
3/8 mini
3/8 mini
3/8 mini
0.325
0.325
0.325
Recommended bar length, min–max, inches
14 – 16
16
16
16
16 – 18
16 – 18
Weight (excl. cutting equipment), lbs
10.7
10.4
10.4
9.7
9.7
11.2
FEATURES
Adjustable oil pump
—
—
—
—
—
—
Air Injection™
•
•
•
•
•
•
AutoTune™
—
—
—
—
—
—
Combined choke /stop control
•
•
•
•
•
•
Purge bulb
•
•
•
•
•
•
Heated carburetor
—
—
—
—
—
—
Heated handles
—
—
—
—
—
—
Inertia chain brake
•
•
•
•
•
•
LowVib®
•
•
•
•
•
•
Magnesium crankcase
—
—
—
—
—
—
Quick-release air filter cover
—
•
•
•
•
•
Quick-release air filter
—
—
•
•
•
•
Retained bar nuts
—
—
—
—
—
—
RevBoost™
—
—
—
—
—
—
Side-mounted chain tensioner
—
—
•
•
•
•
SmartStart®
—
—
•
—
•
•
Snap-lock cylinder cover
—
—
—
•
•
•
Tool-less chain tensioning
—
—
—
—
—
—
TrioBrake™
—
—
—
—
—
—
Visible fuel level
—
—
—
•
•
•
X-Torq® engine
•
•
•
•
•
•
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for different sound pressure levels under various working conditions.
Typical statistical dispersion for equivalent sound pressure level is a standard deviation of 1 dB (A). **Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC. The guaranteed sound
power level includes variation in production as well as variation from the test code with 1–3 dB(A). ***Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for vibration levels under various
working conditions. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
NOMINAL POWER
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard J
1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
For battery chainsaw and pole saw technical specifications, please see page 26.
