ZERO-TURN MOWERS
TECHNICAL SPECIFICATIONS
NOMINAL POWER
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard J
1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
Z554X
Z560X
Z560X
Z560X
TECHNICAL SPECIFICATIONS
Engine manufacturer
Kawasaki
Kawasaki
Kawasaki
Kawasaki
Engine name
FX751
FX850
FX801
FX921
Net power, hp
25.5
27
25.5
31
Fuel tank volume, gallons
12
12
12
12
Transmission type
ZT5400
ZT5400
ZT5400
ZT5400
Transmission manufacturer
Hydro-Gear®
Hydro-Gear®
Hydro-Gear®
Hydro-Gear®
Pump displacement
16 cc
16 cc
16 cc
16 cc
Speed forward, min - max, mph
0 – 12
0 – 12
0 – 12
0 – 12
Speed reverse, min - max, mph
0 – 6
0 – 6
0 – 6
0 – 6
Cutting methods, Collection / Mulch / Side discharge C / M / D
C / M / D
C / M / D
C / M / D
Cutting width, inches
54
60
60
60
Cutting height, min - max, inches
1 – 5
1 – 5
1 – 5
1 – 5
Cutting deck type / gauge
Fabricated 7 Ga.
Fabricated 7 Ga.
Fabricated 7 Ga.
Fabricated 7 Ga.
Blade spindle type
Cast Iron
Cast Iron
Cast Iron
Cast Iron
Blade engagement
Electric
Electric
Electric
Electric
Seat type
Commercial Suspension Commercial Suspension Commercial Suspension Commercial Suspension
Tire size, front, inch
13 x 6.5 Flat Free
13 x 6.5 Flat Free
13 x 6.5 Flat Free
13 x 6.5 Flat Free
Tire size, rear, inch
24 x 12 – 12
24 x 12 – 12
24 x 12 – 12
24 x 12 – 12
FEATURES
Commercial drive system
•
•
•
•
Rugged frame
•
•
•
•
Armrests
•
•
•
•
Flat-free caster tires
•
•
•
•
Hour meter with service minder
•
•
•
•
CARB version available
—
—
•
—
CUTTING SYSTEMS
Mulch Kit accessory
( • )
( • )
( • )
( • )
Collector accessory
( • )
( • )
( • )
( • )
Dump from Seat (DFS) Collector accessory
( • )
( • )
( • )
( • )
= Available ( ) = Accessory — = Not available
