208 / 253
208
ZERO-TURN MOWERS
TECHNICAL SPECIFICATIONS
Z448
Z454
Z460
Z454X
TECHNICAL SPECIFICATIONS
Engine manufacturer
Kawasaki
Kawasaki
Kawasaki
Kawasaki
Engine name
FS651
FS651
FS691
FX691
Net power, hp
22
22
23
22
Fuel tank volume, gallons
6
6
6
6
Transmission type
HTE10
HTE10
HTE10
HTE12
Transmission manufacturer
Parker Hannifin
Parker Hannifin
Parker Hannifin
Parker Hannifin
Pump displacement
10 cc
10 cc
10 cc
12 cc
Speed forward, min - max, mph
0 – 10
0 – 10
0 – 10
0 – 11
Speed reverse, min - max, mph
0 – 5
0 – 5
0 – 5
0 – 5.5
Cutting methods, Collection / Mulch / Side discharge C / M / D
C / M / D
C / M / D
C / M / D
Cutting width, inches
48
54
60
54
Cutting height, min - max, inches
1.5 – 4.5
1.5 – 4.5
1.5 – 4.5
1.5 – 4.5
Cutting deck type / gauge
Fabricated 10 Ga.
Fabricated 10 Ga.
Fabricated 10 Ga.
Fabricated 10 Ga.
Blade spindle type
Cast Aluminum
Cast Aluminum
Cast Aluminum
Cast Aluminum
Blade engagement
Electric
Electric
Electric
Electric
Seat type
Commercial Deluxe
Commercial Deluxe
Commercial Deluxe
Commercial Deluxe
Tire size, front, inch
13 x 6.5
13 x 6.5
13 x 6.5
13 x 6.5
Tire size, rear, inch
22 x 10 – 10
22 x 10 – 10
22 x 10 – 10
23 x 10.5 – 12
FEATURES
Commercial drive system
•
•
•
•
Rugged frame
•
•
•
•
Armrests
•
•
•
•
Flat-free caster tires
—
—
—
—
Hour meter
•
•
•
•
CARB version available
—
•
—
—
CUTTING SYSTEMS
Mulch Kit accessory
(• )
( • )
( • )
( • )
Collector accessory
(• )
( • )
( • )
( • )
Dump from Seat (DFS) Collector accessory
—
—
—
—
= Available ( ) = Accessory — = Not available
NOMINAL POWER
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard J
1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
