STRING TRIMMERS, BRUSHCUTTERS, FORESTRY CLEARING SAWS & EDGERS
TECHNICAL SPECIFICATIONS
NOMINAL POWER – A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard
J 1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
STRING TRIMMERS
& BRUSHCUTTERS 122C 129C 129L 129R 322L 324L 329L 336FR 430LS
TECHNICAL SPECIFICATIONS only
Cylinder displacement, cc 21.7 27.6 27.6 27.6 22.5 25 27.6 34.6 29.5
Power output, hp 0.8 1.1 1.1 1.1 1.0 1.1 1.1 1.9 1.3
Fuel tank, ounces 12.2 11.6 11.5 11.5 16.9 18.6 16.9 20.3 23.6
Sound pressure level at operators ear, dB(A)* 88 93 95 94 98 — 96 98 95
Sound power level guaranteed (LWA) dB(A)** 104 114 114 114 107 — 114 113 116
Equivalent vibration level (ahv, eq)
front / rear handle, m/s²*** 5.0 / 3.6 3.6 / 3.7 9.9 / 8.9 4.2 / 4.2 5.4 / 4.0 9.1 / 8.2 4.2 / 6.1 3.7 / 2.7 2.6 / 1.7
Weight (excl. cutting equipment), lbs 9.7 9.9 10.5 11.9 9.3 11.2 11.0 15.4 11.2
FEATURES
AutoTune™ • • • • • • • • •
Auto return stop switch — — — — — — — — —
Combi-guard — • • • — — — • —
Ergonomic handle • • • • • • • • •
Purge bulb • • • • • • • • •
Grass bevel gear — • • • • • — • •
High handlebar — — — — — — — — —
LowVib® — — — — • • • — •
Pure gasoline engine — — — — — • — — —
SmartStart® • • • • • • • — •
Soft grip handles • • • — • • • • •
Standalone starter — — — — • • • — •
Tap ’n Go™ trimmer head • • • • • • • • •
Tool-less adjustment harness hook eyelet — — — — — — — — —
Tool-less adjustment of handlebar — — — — — — — • —
X-Torq® engine — — — — • — • • •
7° offset handle bar — — — — • • — • •
HARNESSES
Balance XT™ — — — — — — — — —
Balance X™ — — — — — — — — —
Balance 55 — — — — — — — — —
Balance 35 — — — — — — — • —
Standard double — — — • — — — — —
Standard single — — — — — — — — —
CUTTING EQUIPMENT
• /—/— • /—/— • / (• ) / — • / • /— • / • /— • / — /— • / — /— • / • / • • / — /—
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level, according to ISO 22868, is calculated as the time-weighted energy total for different sound pressure levels under various working conditions.
Typical statistical dispersion for equivalent sound pressure level is a standard deviation of 1 dB (A). **Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC. The guaranteed
sound power level includes variation in production as well as variation from the test code with 1–3 dB(A). ***Equivalent vibration level, according to ISO 22867, is calculated as the time-weighted energy total for vibration levels under
various working conditions. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
ALWAYS USE GENUINE HUSQVARNA LUBRICANTS AND SPARE PARTS FOR YOUR
BRUSHCUTTER OR TRIMMER
These high quality spare parts and lubricants are developed to facilitate the care and maintenance of your Husqvarna equipment and enable
trouble-free operation and storage. Husqvarna recommends regular service done by qualified technicians using only Husqvarna original or
recommended spare parts. This will support the product’s performance and lifetime. See your owner’s manual or consult your Authorized
Husqvarna dealer if any uncertainty occurs.
For battery trimmer technical specifications, please see page 27.
