26 / 253
26
BATTERY SERIES
TECHNICAL SPECIFICATIONS
BATTERY CHAINSAWS
120i
535i XP®
T535i XP®
TECHNICAL SPECIFICATIONS
Battery type
Li-ion
Li-ion
Li-ion
Voltage, V
40
40
40
Motor type
BLDC (brushless)
BLDC (brushless)
BLDC (brushless)
Chain speed max power ft/s
39
66
66
Sound pressure level at operators ear, dB(A)
97
93
93
Sound power level guaranteed (LWA) dB(A)
101
106
106
Equivalent vibration level (ahv, eq) front /rear handle, m/s²*
3.5 / 3.8
2.5 / 2.8
2.0 / 2.4
Chain pitch, inches
3/8
3/8 ⁄ 1/4
3/8 ⁄ 1/4
Recommended bar length, min–max, inches
14
10–14
10–14
Weight (excl. battery and cutting equipment), lbs
6.6
5.3
5.3
FEATURES
Belt eye let
—
—
•
Flip up tank cap
•
•
•
Inertia chain brake
•
•
•
Intuitive keypad
•
•
•
Li-ion power
•
•
•
Retained bar nuts
—
•
•
savE™
•
•
•
Tool-less chain tensioning
•
—
—
Water Protection Level
—
•
•
= Available ( ) = Accessory — = Not available *Equivalent vibration level, according to EN 60745-2-13. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
Declared vibration data from measurements when the machine is fitted with a bar length and recommended chain type. If the machine is fitted with a different bar length, the vibration level may vary by max ± 1.5 m/s².
BATTERY POLE SAWS
115iPT4
530iP4
530iPT5
TECHNICAL SPECIFICATIONS
only
Battery type
Li-ion
Li-ion
Li-ion
Voltage, V
40
40
40
Motor type
PMDC (2 brushed)
BLDC (brushless)
BLDC (brushless)
Chain speed max power ft/s
32
66
66
Sound pressure level at operators ear, dB(A)
92
88
83
Sound power level guaranteed (LWA) dB(A)
93
98
98
Equivalent vibration level (ahv, eq) front /rear handle, m/s²*
2.3 / 2.2
1.0 / 0.9
1.0 / 1.2
Chain pitch, inches
3/8
1 /4
1 /4
Recommended bar length, min–max, inches
10
10-12
10-12
Length, extended, with cutting equipment, inches
86
98
157
Weight (excl. battery and cutting equipment), lbs
7.7
7.6
10.1
FEATURES
Flip up tank cap
•
•
•
Harness eyelet
—
•
•
Intuitive keypad
•
•
•
Li-ion power
•
•
•
Rear impact guard
—
•
•
Retained bar nuts
•
•
•
savE™
•
•
•
Telescopic tube
—
—
•
Water Protection Level
—
•
•
HARNESS
Balance Flex™
—
—
(• )
Single harness
•
•
•
Flexible harness for backpack battery
—
—
—
= Available ( ) = Accessory — = Not available *Equivalent vibration level, according to EN 60745-2-13. Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
Declared vibration data from measurements when the machine is fitted with a bar length and recommended chain type. If the machine is fitted with a different bar length, the vibration level may vary by max ± 1.5 m/s².
