138 / 253
138
LEAF BLOWERS
TECHNICAL SPECIFICATIONS
125B
125BVX
130BT
150BT
TECHNICAL SPECIFICATIONS
only
Cylinder displacement, cc
28
28
29.5
50.2
Power output, hp
1.0
1.0
1.3
2.1
Sound pressure level at operators ear, dB(A)*
94
94
94
92
Sound pressure (15 m), dB(A)
70
70
69
71
Sound power level guaranteed (LWA), dB(A)**
107
107
107
104
Equivalent vibration level (ahv, eq) handle, m/s²***
11.1
11.1
2.5
2.5
Air speed, mph
170
170
145
251
Air flow in housing, ft³/min
470
470
431
710
Air flow in pipe, ft³/min
425
425
360
434
Vac bag capacity, gallons
—
17
—
—
Weight, lbs
9.4
9.6
14.8
22.5
FEATURES
Adjustable handle
—
—
•
•
Air Injection™
—
—
—
—
Auto return stop switch
•
•
—
—
Comfort handle
—
•
•
•
Commercial grade air filter
—
—
—
—
Cruise control
•
•
•
•
Ergonomic handle
—
—
•
•
Ergonomic harness
—
—
•
•
Purge bulb
•
•
•
•
In lined outlet
•
•
—
—
LowVib®
—
—
—
•
Mulching function
—
•
—
—
SmartStart®
—
•
—
—
Vac capable
—
•
—
—
X-Torq® engine
—
—
•
•
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level at the operator’s ear, measured according to EN15503 dB (A). The equivalent sound pressure level value is calculated with a work cycle of a
duration of 1/7 for idling and 6/7 for racing. Reported equivalent sound pressure level for the machine has a typical statistical dispersion (standard deviation) of 1 dB(A). **Noise emissions in the environment measured as sound
power (LWA) in conformity with EC directive 2000/14/EC. The guaranteed sound power level includes variation in production as well as variation from the test code with 1–3 dB(A). ***Equivalent vibrations levels (ahv, eq) at handles,
measured according to EN15503, m/s². The equivalent vibration level value is calculated with a work cycle of a duration of 1/7 idling and 6/7 for racing. Reported data for equivalent vibration level has a typical statistical dispersion
(standard deviation of 1 m/s²).
NOMINAL POWER
–
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard
J 1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
For battery leaf blower technical specifications, please see page 28.
