HEDGE TRIMMERS
122HD45
122HD60
322HD60
325HE3
TECHNICAL SPECIFICATIONS
Cylinder displacement, cc
21.7
21.7
21.7
25.4
Power output, hp
0.8
0.8
0.8
1.34
Sound pressure level at operators ear, dB(A)*
93
94
98
96
Sound power level guaranteed (LWA) dB(A)**
101
101
101
106
Equivalent vibration level (ahv, eq) front / rear handle, m/s²*** 2.9 / 4.9
4.1 / 3.6
4.4 / 4.3
3.1 / 4.0
Length cutting knife, inches
18
24
24
22
Teeth opening, inches
1.1
1.1
1.1
1.1
Cutting speed, cuts / min
4050
4050
4400
4300
Weight, lbs
10.1
10.8
11.2
13.9
FEATURES
Adjustable cutting head
—
—
—
•
Adjustable rear handle
—
•
•
—
Auto return stop switch
•
•
•
•
Purge bulb
•
•
•
•
Low noise engine
•
•
•
—
LowVib®
•
•
•
—
Rear impact guard
—
—
•
—
Remote control
—
—
—
•
SmartStart®
•
•
•
•
Standalone starter
—
—
—
•
Transport mode
—
—
—
—
X-Torq® engine
—
—
—
•
= Available ( ) = Accessory — = Not available *Equivalent sound pressure level at the operator’s ear, measured according to EN ISO 11806 and ISO 22868, dB(A). Reported data for equivalent sound pressure level for the
machine has a typical statistical dispersion (standard deviation) of 1 dB(A). **Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC. Reported sound power level for the
machine has been measured with the original cutting attachment that gives the highest level. The guaranteed sound power level includes variation in production as well as variation from the test code with 1–3 dB(A).
***Equivalent vibration levels (ahv, eq) at handles, measured according to EN ISO 11806 and ISO 22867, m/s². Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s².
NOMINAL POWER
–
A new machinery directive (2006/42/EC) came into force on January 1, 2010, requiring manufacturers to declare the nominal power of engines, in kilowatts (kW). The power rating of the engines indicated
is the average net power output during a normal working situations and meets applicable noise regulations (at specified rpm, see owner manual) of a typical production engine for the engine model measured to SAE standard
J 1349/ISO 1585. Mass production engines may differ from this value. Actual power output for the engine installed in the final machine will depend on the operating speed, environmental conditions and other variables.
TECHNICAL SPECIFICATIONS
For battery hedge trimmer technical specifications, please see page 27.
